Seamless Splicing
Full Flip-Chip COB
Excellent Picture Quality
| Model | AC-091 (H) | AC-121 (H) | AC-091 | AC-121 | AC-151 | AC-181 |
|---|---|---|---|---|---|---|
| Pixel Pitch(mm) | P0.9375 | P1.25 | 0.9375 | P1.25 | P1.5625 | P1.875 |
| Resolution | 640*360 | 480*270 | 640*360 | 480*270 | 384*216 | 320*180 |
| Panel Technology | Full Flip-Chip COB | |||||
| Unit Size (W*H*D) mm | 600*337.5*31 | |||||
| Surface treatment | Matte Black Ffinish | |||||
| Brightness(nits) | 2000 | 2000 | 1200 | 1200 | 1500 | 1500 |
| Contrast Ratio | ≤1,000,000:1 | |||||
| Colour Temperature(K) | 7500K(adjustable) | |||||
| Frame Rate(Hz) | 60 | |||||
| Refresh Rate(Hz) | 3840 | 3840 | 3840 | 3840/7680 | 3840 | 3840 |
| Working Voltage | AC:100~240V,50/60Hz | |||||
| Power Consumption Max(W/m²) | ≤480 | ≤420 | ≤300 | ≤250 | ≤420 | ≤390 |
| Power Consumption AVG(W/m²) | ≤160 | ≤140 | ≤100 | ≤85 | ≤140 | ≤130 |
| Viewing Angle(H./V.) | 170°/170° | |||||
| Lifetime (Hours) | 100000 | |||||
| Operating Temp(C) | -10~+50 | |||||
| Humidity Range(%RH) | 10~80 | |||||
| Unit Weight(kg) | 4.5 | |||||
