HD/4K Pixel to Pixel Resolutions
High Gray Scale at Low Brightness Levels
Ultra light weight
Front installation
Front maintenance
90 degree available
| Model | Uslim 1.2 GOB | Uslim 1.5 GOB | Uslim 1.9 | Uslim 2.5 | Uslim 2.6 | Uslim 3.9 |
|---|---|---|---|---|---|---|
| Pixel Pitch | 1.25mm | 1.5625mm | 1.95mm | 2.5mm | 2.6mm | 3.9mm |
| Pixel Density (dots/m²) | 640000 | 409,600 | 262,144 | 160,000 | 147,456 | 65,536 |
| LEDs Model | SMD1010 | SMD1212 | SMD1515 | SMD1515 | SMD1515 | SMD2020 |
| Module Dimension | 250*250mm | |||||
| Module Resolution | 200*200dots | 160*160dots | 128*128dots | 100*100dots | 96*96dots | 64*64dots |
| Panel Dimension | 1000x500x33mm | (1000x250x33mm | 750x250x33mm | 500x250x33mm) | ||
| Panel Resolution | 800*400dots | 640*320dots | 512*256dots | 400*200dots | 384*192dots | 256*128dots |
| Cabinet material | Die-casting Aluminum | |||||
| Panel Weight | 21kg/m² | |||||
| Brightness | 800nits (indoor), 3000nits (semi-outdoor) | |||||
| Max Power Consumption | 480W/m² | |||||
| Ave Power Consumption | 100-200W/m² | |||||
| Power input voltage | 100-240V/AC50-60Hz | |||||
| Viewing Angle | 160°/160° | |||||
| Operating Temperature | -20~+45°C | |||||
| Refresh Rate | 3840Hz | |||||
| Installation type | Front installation | |||||
| Service type | Front service | |||||
| IP Rating | IP30 | |||||
| Signal Input Source | S-VIDIO,VGA,DVI,HDMI,SDI | |||||
