Support HD
Smart split screen
Multiple interfaces
| SPECIFICATIONS | Indoor | Outdoor | ||
|---|---|---|---|---|
| Model | P2 | P2 | P1.8 | P4 |
| LED type | SMD1515 (GOB optional) | SMD1515 (GOB optional) | SMD1212 (GOB optional) | SMD1921 |
| Pixel density | 250000 dots/㎡ | 250000 dots/㎡ | 288906 dots/㎡ | 62500 dots/㎡ |
| Diameter | 713mm | 713mm | 611mm | 764mm |
| Height | 1270mm | 1750mm | 1700mm | 1556mm |
| Display pixels | 1120X560 dots | 1120X800 dots | 1032X817 dots | 600X360 dots |
| Control mode | Network cable/WIFI/4G cloud control (optional) | |||
| Maintenance mode | Front maintenance | |||
| Brightness | ≥600 nits | ≥600 nits | ≥600 nits | 4500 nits |
| Viewing angle (HVV) | 170°/170° | 170°/170° | 170°/170° | 170°/170° |
| Contrast | 6000 : 1 | 6000 : 1 | 6000 : 1 | 6000 : 1 |
| Drive mode | 1/40 scan | 1/40 scan | 1/40 scan | 1/10 scan |
| Grayscale level | 14-16 bit | 14-16 bit | 14-16 bit | 14-16 bit |
| Refresh rate | 3840 Hz | 3840 Hz | 3840 Hz | 3840 Hz |
| Maximum power consumption | 1200 W/set | 1700 W/set | 1500 W/set | 2000 W/set |
| Average power consumption | 400 W/set | 560 W/set | 500 W/set | 600 W/set |
| Power input voltage | AC90-264V,47-63Hz | |||
| Working temperature/humidity range | -20~50℃/10%~85% | |||
| Storage temperature/humidity range | -20~50℃/10%~85% | |||
| Net weight | 65kg | 91kg | 68kg | 120kg |
| Gross weight(wooden case) | 133kg | 160kg | 142kg | 205kg |
| Packing size(wooden case) | 900*900*1490mm | 900*900*1950mm | 900*900*1920mm | 900*900*1750mm |
| Gross weight(flight case) | 130kg | 170kg | 145kg | 210kg |
| Packing size(flight case) | 890*890*1530mm | 890*890*2020mm | 950*950*1900mm | 890*890*1750mm |
